A precision scale structural model of an off-grid lakefront lofted A-frame home. Features pressure-treated foundation skids, engineered subfloor assembly, structural A-frame rafter trusses with exterior plywood gussets, mid-height loft flooring framing, and full shear wall end gables designed for high wind load resistance and moisture management.
intermediate wood other
Dimensions: {"unit":"in","depth":12,"width":24,"height":36,"autoEstimate":true}
Materials
- 2x2 Pressure-Treated Lumber (Actual 1.5" x 1.5")
- 1x2 Douglas Fir S4S (Actual 0.75" x 1.5")
- 1/2" ACX Exterior Grade Plywood
Tools Required
- Table saw with 10" 60T combination blade
- Miter saw with bevel/miter crosscut capacity
- Brad nailer (18 gauge) or micro-pinner
- Parallel jaw clamps (24" and 40" capacity)
- Digital angle gauge / protractor
- Framing square and speed square
- PVA Wood Glue (Titebond III Waterproof)
