A heavy-duty, heirloom-quality kitchen storage hutch engineered specifically to hold heavy stoneware, ceramic plates, bowls, and heavy cast-iron cookware. This design features a robust central vertical partition to completely eliminate shelf sag over the 48-inch span, coupled with blind dado joinery and a solid face frame to prevent racking and bowing under loads up to 150 lbs per shelf level.
intermediate wood other
Dimensions: {"unit":"in","depth":24,"width":48,"height":60,"autoEstimate":false}
Materials
- 3/4" Paint-Grade Birch Plywood (4' x 8')
- 1/4" Paint-Grade Birch Plywood (4' x 8')
- 1x2 Solid Poplar Lumber (8' length)
- 1x1 Solid Poplar Lumber (8' length)
Tools Required
- Table saw with 10" 50-tooth combination blade
- Dado blade set (for cutting 3/8" deep by 3/4" wide blind dadoes)
- Pocket hole jig and stepped drill bit
- Router with 1/4" rabbeting bit
- Plunge router with 1/4" straight bit and shelf pin jig
- Pneumatic 18-gauge brad nailer
- Parallel jaw bar clamps (minimum four 48" clamps)
- Random orbital sander with 120 and 220 grit sandpaper
